What is Node Red? –Node red is a Open Source flow based tool and IOT platform and Dashboard developed by IBM and written in Node.js.
Node-red lets you easily build applications by joining together black box functions (nodes) using a web interface, and it requires very little, if any, programming knowledge.
Because of its flexibility and ease of use node-red is ideally suited for building IOT and Home control dashboards and automations as well as many other applications.
Node-red can be installed locally on Windows and Linux and also because of its small size also on the raspberry Pi.
It is also available as a cloud server from IBM and others like FRED
Node-Red Overview
Here is a the official introductory video from the node-red team which give you a good overview of what node-red is.
Node-Red Tutorials – Quick Links
- Getting started
- Node-Red Admin
- Node-Red programming
- Node-Red Dashboards
- Node-Red Data storage
- Node-Red IOT and Home Automation
- Videos
Getting Started
Before you can use node-red locally you will need to install it and start it running.
This tutorial Installing and Starting Node-Red explains how to do that.
The next step is to become familiar with the admin interface and learn how to create and manage flows.
Node-red works by passing messages between nodes and this is critical to understand before you start wiring nodes together and is explained in Understanding The Node-Red Message Object
